牌号简介 About |
---|
Elix Ultra HH 4115 Hi超高耐热abs,具有极强的抗冲击性ISO shortname:ISO 2580-1 abs 2-x,mg,115-15-35-20优点:具有极强的抗冲击性,低温延展性,极高的抗冲击性,高达-30°C,流动性和耐热性良好,比PC/abs低密度,低排放和气味等级,低模具沉积。其在注塑加工中的应用较好的尺寸热下化学成分:聚碳酸酯改性的丙烯腈-丁二烯-苯乙烯共聚物(ABS)和聚(苯乙烯-马来酰亚胺) ELIX ULTRA HH 4115 HI Very high heat resistance ABS with extreme impact resistance ISO shortname: ISO 2580-1 ABS 2-X, MG, 115-15-35-20 Major Benefits: Extreme impact resistance with low temperature ductility Very high impact up to -30°C Well balanced flowability and heat resistance Lower density than PC/ABS Low emission and odor grade Lower mould deposits in injection molding processing applications Better dimensional under heat Chemical Composition: Acrylonitrile-butadiene-styrene (ABS) copolymer modified with polycarbonate and poly(styrene-co-maleimide) |
技术参数 Technical Data | |||
---|---|---|---|
物理性能 PHYSICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
密度 Density |
|||
25℃ 25℃ |
1.07 | g/cm³ | ISO 1183 |
熔体体积流动速率 Melt Volume Rate |
|||
260℃,5 kg 260℃,5 kg |
14.0 | cm³/10min | ISO 1133 |
收缩率 Shrinkage rate 2 |
ISO 2577 | ||
TD TD |
0.65 to 0.75 | % | ISO 2577 |
MD MD |
0.65 to 0.75 | % | ISO 2577 |
冲击性能 IMPACT |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
简支梁缺口冲击强度 Charpy Notched Impact Strength |
ISO 179/1eA | ||
-30℃ -30℃ |
40 | kJ/m² | ISO 179/1eA |
23℃ 23℃ |
kJ/m² | ISO 179/1eA | |
悬臂梁缺口冲击强度 Impact strength of cantilever beam notch |
ISO 180/1A | ||
-30℃ -30℃ |
kJ/m² | ISO 180-1A | |
23℃ 23℃ |
kJ/m² | ISO 180-1A | |
热性能 THERMAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
热变形温度 Hot deformation temperature |
|||
1.8 MPa,退火 1.8 MPa, annealed |
℃ | ISO 75-2/A | |
0.45 MPa,退火 0.45 MPa, annealed |
℃ | ISO 75-2/B | |
维卡软化温度 Vicat Softening Temp |
|||
B50 B50 |
℃ | ISO 306 | |
B120 B120 |
℃ | ISO 306/B120 | |
线性热膨胀系数 Linear coefficient of thermal expansion |
|||
MD:23~55℃ MD:23~55℃ |
1/℃ | ISO 11359-2 | |
阻燃性能 FLAME CHARACTERISTICS |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
1.60 mm 1.60 mm |
UL 94 | ||
燃烧速率 Burning rate 4 |
|||
2.0 mm 2.0 mm 4 |
mm/min | ISO 3795 | |
碳排放 carbon emission |
|||
Total,23℃ Total,23℃ |
µgC/g | VDA 277 | |
补充信息 Supplementary information |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
排放 discharge |
VDA 278 | ||
FOG total:23℃ FOG total:23℃ |
µg/g | VDA 278 | |
VOC total:23℃ VOC total:23℃ |
µg/g | VDA 278 | |
机械性能 MECHANICAL |
额定值 Nominal Value |
单位 Units |
测试方法 Test Method |
拉伸模量 Tensile modulus |
|||
23℃ 23℃ |
MPa | ISO 527-1-2 | |
拉伸强度 tensile strength |
|||
屈服,23℃ Yield, 23 ℃ |
MPa | ISO 527-2/50 | |
拉伸应变 Tensile strain |
|||
断裂,23℃ Fracture, 23 ℃ |
% | ISO 527-2/50 | |
屈服,23℃ Yield, 23 ℃ |
% | ISO 527-2/50 | |
标称拉伸断裂应变 Nominal tensile fracture strain |
|||
23℃ 23℃ |
% | ISO 527-2/50 | |
弯曲模量 Bending modulus 3 |
|||
23℃ 23℃ 3 |
MPa | ISO 178 | |
弯曲强度 bending strength 3 |
|||
23℃ 23℃ |
MPa | ISO 178 | |
球压硬度 Ball hardness |
MPa | ISO 2039-1 |
备注 |
---|
1 一般属性:这些不能被视为规格。 |
2 60x60x2 mm |
3 0.079 in/min |
4 US - FMVSS |
